New
Gigabyte MS04-CE0
P/N: 9MS04CE0MR-00
1 105€ (inc. VAT (Spain))
Delivery is made within 3-7 days
This is an estimated timeframe. Delivery times may vary depending on logistics and stock availability.
Warranty 2 year
The product is covered by the manufacturer’s standard warranty.
In stock
Guaranteed Safe Checkout:
Gigabyte MS04-CE0 workstation motherboard with fast EU delivery and worldwide shipping. Best price in the European Union. Includes official warranty.
Expert support On-line
Our specialist will help you choose the right server components and ensure full compatibility with your system.
Technical Specifications Product
| Weight | 2 kg |
|---|---|
| Dimensions | 38 × 31 × 8 cm |
| Country of manufacture | China, Taiwan |
| Manufacturer's warranty (years) | 1 |
| Model | MS04-CE0 |
| Memory type | DDR5 RDIMM, DDR5/MRDIMM |
| Maximum memory capacity | 2TB |
| Processors on a motherboard | 1 |
| Length (cm) | 38 |
| Width (cm) | 31 |
| Weight (kg) | 2 |
| Socket | LGA 4710 |
| Chipset | System on Chip |
| Max Supported CPU TDP (W) | 350 |
| Number of DIMM Slots | 8 |
| Number of LAN Ports | 2 |
| Integrated LAN Controller | 2x 1Gb/s (Intel I210-AT) |
| Form Factor | ATX |
| Integrated RAID Controller | ASPEED AST2600 |
Product description
GIGABYTE MS04-CE0 – Standard ATX Server Platform for Intel Xeon 6 featuring PCIe 5.0 and MRDIMM Support
The GIGABYTE MS04-CE0 redefines the capabilities of standard-sized infrastructure. Built on the cutting-edge Intel Xeon 6 architecture (LGA4710), this motherboard brings the density of enterprise computing to a widely compatible ATX form factor (305W x 244D mm). It is engineered to support the latest “Sierra Forest” and “Granite Rapids” processors with thermal envelopes up to 350W, making it a prime candidate for versatile enterprise servers and high-end professional workstations that require maximum compatibility with existing chassis ecosystems.
Optimized Memory Performance: 1DPC Architecture
To maximize data throughput without compromising signal integrity, the board employs a 1DPC (One DIMM Per Channel) design across eight memory slots. This layout is optimized for next-generation DDR5 MRDIMM technology, allowing compatible P-core processors to reach transfer speeds of 8000 MT/s. For standard deployments, it supports robust ECC RDIMM modules at 6400 MT/s, ensuring that memory-intensive virtualization and database workloads run with zero latency and high stability.
High-Bandwidth Expansion in a Compact Footprint
Despite its compact ATX dimensions, the MS04-CE0 offers an expansion capability usually reserved for larger E-ATX boards. It features five PCIe 5.0 slots (four wired x16, one wired x8), providing a massive bandwidth pipeline for modern peripherals. This allows system integrators to stack multiple GPU accelerators, 100GbE network interface cards, or RAID controllers, transforming a standard mid-tower chassis into a powerhouse calculation node.
Storage Flexibility and Connectivity
Storage requirements are met through a high-density connection approach:
- Mass Storage: Three onboard SlimSAS 4i connectors utilize the chipset to provide connectivity for up to 12 SATA 6Gb/s drives, creating a robust foundation for local data archiving.
- System Acceleration: Two M.2 Gen5 x2 slots (supporting 2280/22110 lengths) are strategically placed for boot drives or NVMe caching, supporting Intel VROC for bootable RAID configurations.
Remote Administration and Network Integration
Reliable utility connectivity is ensured via dual Intel I210-AT Gigabit Ethernet ports. However, the true strength lies in its remote administration capabilities, powered by the ASPEED AST2600 BMC. This dedicated processor enables full IPMI 2.0 control and HTML5 KVM-over-IP, allowing IT teams to monitor thermal sensors, update BIOS/CPLD firmware, and manage power states from anywhere in the world. It also supports NCSI, allowing the management traffic to share the bandwidth of a compatible OCP networking card if installed.
Target Deployment Scenarios
- Edge Computing Servers: Leveraging the standard ATX size to fit into short-depth rackmount cases.
- Engineering Workstations: Utilizing the high core count of Xeon 6 and multi-GPU support for CAD/CAE.
- File & Backup Servers: Capitalizing on the 12x SATA ports for cost-effective, high-capacity storage.
Technical Specifications Summary
- Platform Core: Intel Xeon 6 (LGA4710 / Socket E2) / Up to 350W TDP
- Memory Standard: 8 DIMMs, DDR5 MRDIMM (8000 MT/s) & RDIMM support
- Expansion Slots: 4x PCIe Gen5 x16 + 1x PCIe Gen5 x8
- Storage I/O: 3x SlimSAS (12x SATA), 2x M.2 Gen5
- Networking: 2x 1GbE (Intel I210) + Dedicated Management LAN
- Management: ASPEED AST2600 BMC (IPMI / KVM)
- Form Factor: ATX (12″ x 9.6″)
Product reviews
0
50
40
30
20
10
Only logged in customers who have purchased this product may leave a review.
Product Berchmark
Overview and Analysis of the Gigabyte MS04-CE0 Motherboard
The Gigabyte MS04-CE0 is a high-performance single-socket ATX server motherboard designed for the latest processors based on the LGA 4710 socket (6th Gen Intel Xeon). This model represents a compact yet powerful platform that delivers enterprise-level compute density within a standard form factor, making it a versatile solution for modern data centers and corporate infrastructures.
The board is optimized and designed for the following tasks:
- Edge Computing: Thanks to its compact ATX format, the board easily integrates into small server nodes for data processing at the edge.
- Web Servers and Enterprise Services: Support for the latest high-performance processors ensures fast processing of multiple concurrent requests.
- Entry to Mid-level Virtualization Systems: Support for up to 2 TB of high-speed DDR5 memory allows running a large number of virtual machines on a single physical server.
- Data Analytics and Processing: The use of new MRDIMM/RDIMM memory standards minimizes data access latency, which is critical for databases.
Comparative Technical Specifications Table
Below is a comparison of the Gigabyte MS04-CE0 with key competitors on the LGA 4710 platform.
| Model | Form Factor | Max Processors | Chipset | Memory Type | Max RAM* | LAN Ports | TDP (W) |
|---|---|---|---|---|---|---|---|
| Gigabyte MS04-CE0 | ATX | 1 | System on Chip | 8x DDR5 MRDIMM/RDIMM | 2TB | 2x 1Gb/s | 350 |
| Supermicro X14SBI-F | ATX | 1 | System on Chip | 8x DDR5 MRDIMM/RDIMM | 512GB/2TB | 2x 1Gb/s | 350 |
| Supermicro X14DBI-T | E-ATX | 2 | System on Chip | 16x DDR5 MRDIMM/RDIMM | 1TB/4TB | 2x 10Gb/s | 350 |
| Gigabyte MS74-HB0 | E-ATX | 2 | System on Chip | 16x DDR5 MRDIMM/RDIMM | 4TB | 2x 1Gb/s/ 2x 10Gb/s |
350 |
*RAM — Random Access Memory.
Analysis of Gigabyte MS04-CE0 Strengths
Based on the technical specifications, we can highlight several strengths of the Gigabyte MS04-CE0 compared to competing solutions on the LGA 4710 socket:
- Perfect balance of performance and compactness: Unlike bulky dual-socket E-ATX solutions (Supermicro X14DBI-T and Gigabyte MS74-HB0), the MS04-CE0 model is built in the standard ATX format. This allows the use of compact and widely available server chassis while maintaining the processor’s ability to operate at its full 350W Thermal Design Power (TDP) without losing computing power.
- Maximum memory support in its class: In direct comparison with its closest single-socket competitor (Supermicro X14SBI-F), the Gigabyte board offers guaranteed and transparent support for up to 2 TB of innovative DDR5 MRDIMM/RDIMM memory, providing maximum bandwidth for resource-intensive applications.
- High computing capacity: Support for processors with a 350W TDP indicates a robust power delivery subsystem. This guarantees stable operation of the highest-end multi-core processors on the LGA 4710 platform at maximum frequencies.
- Energy efficiency and network pragmatism: The presence of standard 2x 1Gb/s ports makes the board versatile for most infrastructure tasks that do not require excessive network bandwidth, leaving PCIe lanes free for installing specialized network adapters if necessary.
Conclusion
The Gigabyte MS04-CE0 is a benchmark single-socket platform for the new generation of server computing on the LGA 4710 socket. It combines the highest memory density (up to 2 TB of the latest DDR5 MRDIMM), full support for the most powerful processors (350W), and the flexibility of the standard ATX form factor. It is the ideal choice for building balanced, powerful, and compact nodes capable of handling enterprise-level tasks without the unnecessary complexity of dual-processor systems.
Product FAQ
This model is equipped with the latest LGA 4710 socket and is designed specifically for 6th generation Intel Xeon server processors. The board is capable of handling powerful processors with a Thermal Design Power (TDP) of up to 350W, allowing the use of the platform’s flagship multi-core solutions.
The board features 8 DIMM slots. It supports the installation of a massive capacity — up to 2 TB of high-speed DDR5 server memory. A distinctive feature is the support for both standard RDIMM modules and the latest MRDIMMs, which provide extremely high bandwidth.
Yes, one of the main advantages of the Gigabyte MS04-CE0 is its form factor. It is a standard ATX size board (305 mm x 244 mm). You will be able to install it in most classic server chassis (1U/2U/4U rackmounts) and tower cases without any problems, unlike larger E-ATX server boards.
No, this model is a single-processor (1S) board. It is designed to provide maximum computing density within a single socket. If you require a dual-processor system, you will need larger E-ATX form factor motherboards.
The motherboard is equipped with two built-in Gigabit ports (1GbE Base-T) for local network connection. This makes it cost-effective for tasks where an ultra-fast built-in network is not required. If speeds of 10/25/100 Gbps are needed, you can easily install the required network adapter into a PCIe slot.
Yes, the platform fully supports the advanced PCIe 5.0 standard. This ensures there are no bottlenecks when connecting modern NVMe drives, ultra-fast network cards, and computing graphics accelerators.
The board features a built-in BMC controller (ASPEED AST2600) and a dedicated management network port (Management LAN). This gives administrators full remote control over the server (via IPMI 2.0, Redfish, KVM-over-IP): you can remotely turn the system on/off, update the BIOS, and monitor temperatures.
The Gigabyte MS04-CE0 is perfectly suited for corporate web servers, small to medium-scale virtualization environments, database analytics nodes, and Edge Computing, where the high performance of Intel Xeon and a huge amount of RAM are required, but space is limited by a standard ATX case.
Yes, given the support for processors with a 350W TDP, you will need a specialized server cooler (heatsink) compatible with the LGA 4710 socket. Additionally, the server chassis itself must be equipped with powerful fans to create directed airflow. Standard home PC fans will not be suitable for this platform.
